HF 13.56Mhz RFID Mifare Reader/Writer-USB/RS232 interface ISO14443A standard from China manufacturer

Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)

Product Detail

Model No.: IOT5301W

Production Capacity: 8000

Means of Transport: Air

Delivery Date: 3-4 working days

rfid smart card reader, rfid/nfc mifare reader/writer, HF 13.56Mhz rfid/mifare reader/writer, iso 14443A standard, USB interface

Key Features:

Adopts ARM Cortex M3 chipset

Available with 64kb Flash memory and 20kb RAM

Compliant with ISO1443A,B standard

With 2 SAM card socket, ISO7816 protocol (optional)

Multiple ISO standard protocols conform

Support contactless CPU cards;

USB working mode, plug and play

Multi interface for options;

One Buzzer and LED indication

Technical Parameters:

Parameters
Frequency	13.56Mhz
Protocol	ISO/IEC 14443A, ISO 7816 standard
Cards support	Mifare One S50; Mifare Ultralight; Mifare OneS70, MifarePro, NTAG 203/205/213/215/216 Contactless CPU series cards ISO7816 standard SAM cards (optional)
Reading speed	Default 0.1s (adjustable by command)
Port	USB/RS232/RS485
Baudrate	9600-115200bit/s(configurable,default 9600)
Reading range	50~80mm (depend on tag size)
Current	<150mA
Voltage	5V DC or USB port
Working temp	-20℃ to +70℃
Storage temp	-20℃ ~ +80℃
Indication	One Bio-color LED and buzzer
Dimension	99mmx99mmx22mm
